型号 |
流量
m³/h |
扬程
m |
电压/频率
V/Hz |
功 率
KW/Hp |
配管内径
mm |
净重
KGS |
毛重
KGS |
包装尺寸
MM |
|
QDN3-5-0.12KW
QN3-5-0.12KW |
3
MAX:6 |
5
Max：6 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.12KW
(1/6HP) |
25 |
5 |
5.2 |
140*140*335 |
|
QDN1.5-7-0.12KW
QN1.5-7-0.12KW |
1.5
MAX:6 |
7
MAX:8 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.12KW
(1/6HP) |
25 |
5 |
5.2 |
140*140*335 |
|
QDN3-8-0.18KW
QN3-8-0.18KW |
3
MAX:6 |
8
MAX:10 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.18KW
(6/25HP) |
25 |
6.25 |
6.5 |
140*140*380 |
|
QDN5-7-0.25KW
QN5-7-0.25KW |
5
MAX:10 |
7
MAX:9 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.25KW
(1/3HP) |
40 |
7.3 |
7.6 |
165*165*375 |
|
QDN5-10-0.37KW
QN5-10-0.37KW |
5
MAX:8 |
10
MAX:12 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.37KW
(49/100HP) |
40 |
8.2 |
8.5 |
165*165*380 |
|
QDN6-14-0.55KW
QN6-14-0.55KW |
6
MAX:13 |
14
MAX:18 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.55KW
(3/4HP) |
50 |
11.8 |
12.3 |
220*220*445 |
|
QDN10-10-0.75KW
QN10-10-0.75KW |
10
MAX:14 |
10
MAX:14 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.75KW
(1HP) |
50 |
12.4 |
12.9 |
220*220*445 |
|
QDN25-6-0.75KW
QN25-6-0.75KW |
25
MAX:33 |
6
MAX:10 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.75KW
(1HP) |
65 |
12.8 |
13.3 |
220*220*455 |
|
QDN15-14-1.1KW
QN15-14-11.1KW |
15
MAX:20 |
14
MAX:17 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.1KW
(1.5HP) |
50 |
13.9 |
14.5 |
220*220*470 |
|
QDN25-9-1.KW
QN25-9-1.1KW |
25
MAX:40 |
9
MAX:12 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.1KW
(1.5HP) |
65 |
13.9 |
14.3 |
220*220*465 |
|
QDN40-6-1.1KW
QN40-6-1.1KW |
40
MAX:50 |
6
MAX:10 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.1KW
(1.5HP) |
65 |
13.9 |
14.3 |
220*220*465 |
|
QDN3-25-0.55KW
QN3-25-0.55KW |
3
MAX:11 |
25
MAX:27 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.55KW
(3/4HP) |
50 |
12.9 |
13.3 |
220*220*460 |
|
QDN3-30-0.75KW
QN3-30-0.75KW |
3
MAX:12 |
30
MAX:33 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
0.75KW
(1HP) |
50 |
14 |
14.5 |
220*220*465 |
|
QDN3-35-1.1KW
QN3-35-1.1KW |
3
MAX:12 |
35
MAX:38 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.1KW
(1.5HP) |
50 |
12.9 |
13.3 |
220*220*460 |
|
QDN6-24-1.1KW
QN6-24-1.1KW |
6
MAX:20 |
24
MAX:28 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.1KW
(1.5HP) |
50 |
15.5 |
16 |
220*220*485 |
|
QDN8-20-1.1KW
QN8-20-1.1KW |
8
MAX:20 |
20
MAX:25 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.1KW
(1.5HP) |
50 |
15.5 |
16 |
220*220*485 |
|
QDN6-30-1.5KW
QN6-30-1.5KW |
6
MAX:16 |
30
MAX:33 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.5KW
(2HP) |
50 |
16.5 |
17 |
220*220*530 |
|
QDN10-20-1.5KW
QN10-20-1.5KW |
10
MAX:25 |
20
MAX:25 |
220V/50Hz 220V/60Hz
380V/50Hz 110V/60Hz |
1.5KW
(2HP) |
50 |
16.5 |
17 |
220*220*530 |
|
QN10-32-2.2KW |
10
MAX:30 |
32
MAX:38 |
380V/50Hz |
2.2KW
(3HP) |
65 |
26.5 |
28 |
220*220*640 |
|
QN15-34-3KW |
15
MAX:33 |
34
MAX:38 |
380V/50Hz |
3KW
(4HP) |
65 |
28 |
30 |
220*220*660 |
|
QN25-17-2.2KW |
25
MAX:30 |
17
MAX:20 |
380V/50Hz |
2.2KW
(3HP) |
65 |
25.75 |
27 |
/ |
|
QN65-7-2.2KW |
65
MAX:78 |
7
MAX:10 |
380V/50Hz |
2.2KW
(3HP) |
100 |
28 |
29 |
/ |
|
QN15-25-2.2KW |
15
MAX:33 |
25
MAX:30 |
380V/50Hz |
2.2KW
(3HP) |
65 |
26 |
28 |
/ |
|
QN20-20-2.2KW |
20
MAX:45 |
20
MAX:30 |
380V/50Hz |
2.2KW
(3HP) |
65 |
30 |
28 |
/ |
|
QN24-25-3KW |
24
MAX:45 |
25
MAX:30 |
380V/50Hz |
3KW
(4HP) |
65 |
30 |
33 |
/ |
|
QN65-10-3KW |
65
MAX:78 |
10
MAX:13 |
380V/50Hz |
3KW
(4HP) |
100 |
30 |
33 |
/ |
|
QN40-16-3KW |
40
MAX:48 |
16
MAX:20 |
380V/50Hz |
3KW
(4HP) |
80 |
41 |
42 |
/ |
|
QN15-40-4KW |
15
MAX:40 |
40
MAX:45 |
380V/50Hz |
4KW
(5.3HP) |
65 |
45 |
47 |
/ |
|
QN20-35-4KW |
20
MAX:50 |
35
MAX:40 |
380V/50Hz |
4KW
(5.3HP) |
65 |
45 |
47 |
/ |
|
QN75-10-4KW |
75
MAX:100 |
10
MAX:15 |
380V/50Hz |
4KW
(5.3HP) |
65 |
45 |
47 |
/ |
|
QN40-21-4KW |
40
MAX:70 |
21
MAX:25 |
380V/50Hz |
4KW
(5.3HP) |
80 |
36.7 |
39 |
/ |
|
QN100-12-5.5KW |
100
MAX:120 |
12
MAX:15 |
380V/50Hz |
5.5KW
(7.3HP) |
120 |
80 |
85 |
/ |
|
QN160-11-7.5KW |
160
MAX:180 |
11
MAX:15 |
380V/50Hz |
7.5KW
(10HP) |
150 |
100 |
106 |
/ |
|
QN100-25-11KW |
100
MAX:130 |
25
MAX:33 |
380V/50Hz |
11KW
(14.67HP) |
120 |
150 |
165 |
/ |
|
QN250-12-15KW |
250
MAX:280 |
12
MAX:20 |
380V/50Hz |
15KW
(20HP) |
250 |
190 |
195 |
/ |
|
QN400-10-18.5KW |
400
MAX:450 |
10
MAX:15 |
380V/50Hz |
18.5KW
(24.6HP) |
400 |
220 |
230 |
/ |
|
QN120-40-22KW |
120
MAX:140 |
40
MAX:47 |
380V/50Hz |
22KW
(29.3HP) |
150 |
262 |
272 |
/ |
